Verona’s 48" Designer Series wall mounted chimney hood features 4 fan speeds, time delay shut-off, stainless steel baffle filters, and 4 LED lights.
The Verona chimney hood has a clean, straight-line design with rounded edges for a pro-style look that will add beauty and performance to any space.
A stainless steel 5-button back-lit keypad allows for easy adjustment of the fan speed, operation of the LED work lights and auto shut-off timer.
The hood is designed with a telescopic chimney that extends to fit 8 ft. ceiling heights, an extension for up to 12 ft. ceiling heights is available.
Additional features include:
- Stainless steel, anti-grease baffle filters that are dishwasher-safe.
- 1200-CFM motor for powerful ventilation of grease, smoke and odors from the kitchen.
- Light indicator for grease filter maintenance.
For external ventilation, a 8" inch round duct is required.
For interior venting installation, an optional filtration kit is required.
Features
- 1,200 CFM
- 4 Fan Speeds
- Delayed Power Shut Off
- 4 LED Lights
- 3 Stainless Baffle Filters
- All Stainless Steel
- Welded Seamless Edges
- Light Indicator for Grease Filter Maintenance
- Light Indicator for Charcoal Filter Replacement
Specifications
- Duct size: 8” (200 mm)
- Width: 47¹⁵⁄₁₆” | Height: 32 ⁹⁄ᶾ₂” – 47¼” | Depth: 21”
- 120V 60 Hz 15 AMP
- 75 lbs.
Manuals/Downloads
Attachment | Size |
---|---|
395579_instructions_canopy_wall_ec_en_0.pdf | 687.5 KB |
Attachment | Size |
---|---|
vechw48gss_spec_sheet.pdf | 276.78 KB |
Accessories
Ductless Conversion Kit allows the range hood to re-circulate air when outdoor venting is not available.
